YD-5000 Automatic servo motor blow moulding machine

product image thumb
product image thumb
product image thumb
product image thumb
product image thumb

YD-5000 Automatic servo motor blow moulding machine

1.High quality compact machine Most popular pet bottle blowing machine YC-9000 With touch screen, Use Festo ( German brand) , SMC (Japan brand ) & Parker ( U.S.A Brand) pneumatic components. PLC use Mitsubishi (Japan brand)

2.Nontoxic conveyor belt to carry preforms

3.Produce PET Bottles ( such as: wine, beverage, soybean, vinegar bottles and so on)

4. Easy to maintain

5. Infrared lamps

6.High safety. high speed with high efficiency.

7.Manual saving, one man is enough for operation the machine.

8.Stable performing with easy maintaining.

9.Imported PLC controlling and man-machine interface computer.

10.Japan Omron inspection sensor.

11.Adopt the new type double bend arm and the four rod-clamping structure(won the patent): Cross direction; Middle mould board is move parallel; the distance between two mold board is adjusted by the chain wheel. Thus, the clamping force is very strong.

12.Power saving design that can increase your profits.

13.Segregate type air controlling system, which is designed for avoiding waste pollution.


Tag: blow,machine,automatic,YD-5000,servo,motor,moulding

Description

YD series linear bottle blowing machine features:

  1. stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system.

    2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety.

    3. servo transmission system, high positioning accuracy, fast speed, good stability and reliability.

    4. suitable for flexible production of small quantity and various bottle shape,wide range of applications,meet customer needs.

    5. increase energy using efficiency,increase productivity per unit of time.

    6. manual and automatic methods of operation, human-machine interface control, simple operation.

    7. servo transmission system, high positioning accuracy, fast speed stability and good reliability.

    8. safety self-locking device in each mechanical action,when a certain process fails, the program will automatically switch to a safe state.

    9. less than 0.2% scrap rate for finished bottle .


General InformationYD-5000   4 cavity
Clamping Force40T
Clamping Stroke125mm
Max.Stretching Stroke400mm
Bottle Moving Stroke0-50mm
Cavity No.4cavity
Output4000-5000BPH
Max.Mould Thickness300mm

Space Between Tie Bars

100mm
Mould Plate Size670x650mm
High pressure Air compressor4.8m³/min   3.0Mpa
Low pressure Air compressor1.6m³/min   1.0Mpa
Voltage Standard380V/3PH/50Hz
Heating Zone No.4 Sections
Total Power 50KW
Bottle Volume0.1-2.0L
Neck Diameter Range16-38mm
Max.Bottle Diameter115mm
Bottle Height360mm
High-pressure System3.0-4.0Mpa
Low-pressure System0.8-1.0Mpa
Machine Size355x160x200cm
Auto-loader110x120x220cm
Net Weight3.8T
