YD-A9-PP Semi-automatic blow moulding mahcine
Main Features
1. Produce bottle from 0.1L to 2L(2 cavity)
2. Output capacity up to 900 for 0.6L using two-cavity blow mold
3. Advanced PLC control system with a use-friendly panel and time-control precision of PLC up to 0.01second
4. Equipped with special designed air storage unit
5. Using Infrared preform heater
6. Independent Temperature Control for different heating lamp to get ideal preform heating results
7. Heating lamps are adjustable in directions to suit various preforms.
8. Operated only by one person without special training.
9. Simple installation & startup adjustment.
| General Information | YD-A3 FOR PP One Blower And One Heater | YD-A3 FOR PP Two Blower And One Heater |
| Clamping Force | 12T | |
| Clamping Stoke | 220mm | |
| Max.Stretching Stroke | 360mm | |
| Number of Cavities | 2 Cavity | 2 Cavity 2Pcs |
| Theoretical Output | 0.3-2.5L:500-800 BPH | 0.3-2.5L:900-1500 BPH |
| Max.Mould Thickness | 250mm | |
| Mould plate size | 490x410mm | |
| Voltage Standard | 380v/3PH/50Hz or special order | |
| Total Power(Full Loaded) | 5-20KW | 10-25KW |
| Min air compressor | 1.0m3/min 3.0Mpa | 1.6m3/min 3.0Mpa |
Net dimension & Weight(LxWxH) | ||
| Blow Molding Machine | 160x60x175cm | 160x60x175cm 2Pcs |
| Pre-heater | 450x72x150cm | |
| Net Weight | 1.8T | 2.6T |
Container | ||
| Container Volume | 0.3-2.5L | |
| Neck Diameter Range | 8-60mm | |
| Container Diameter | 140mm | |
| Container Height | 380mm | |
