YD-1500 One Blower And One Heater
YD-1500 PET blow moulding machine has a plenty of assistant units to
increase the machine's performance such as air storage unit to keep the
air pressure stable grease-lubricating unit to reduce mechanical parts'
wear and tear and multi-utilization air entry unit to meet air
compressed air high-pressure single entry mode and high-pressure &
low-pressure double entry mode.
General Information | YD-1500 One Blower And One Heater | YD-1500 Two Blower And One Heater |
Clamping Force | 10T | |
Clamping Stoke | 160mm | |
Max.Stretching Stroke | 360mm | |
Number of Cavities | 1 Cavity | 2 Cavity 2Pcs |
Theoretical Output | 0.1-1.5L:600-800 BPH | 0.1-1.5L:1000-1600 BPH |
Max.Mould Thickness | 220mm | |
Mould plate size | 470x350mm | |
Voltage Standard | 380v/3PH/50Hz or special order | |
Total Power(Full Loaded) | 3-10KW | 5-15KW |
Min air compressor | 1.0m3/min 3.0Mpa | 1.2m3/min 3.0Mpa |
Net dimension & Weight(LxWxH) | ||
| Blow Molding Machine | 145x60x170cm | 145x60x170cm 2Pcs |
| Pre-heater | 180x70x140cm | |
Net Weight | 1.1T | 1.6T |
Container | ||
Container Volume | 1.5L | |
| Neck Diameter Range | 8-60mm | |
| Container Diameter | 115mm | |
| Container Height | 360mm | |
